2007-2010 International MaxxForce 9 & 10 16cc High-Pressure Oil Pump | Alliant Power AP63697 Remanufactured
This is the Alliant Power AP63697, a 16cc high-pressure oil pump (HPOP) remanufactured by Alliant Power for the 2007 to 2010 International / Navistar MaxxForce 9 and MaxxForce 10, engine serial numbers 3,040,001 through 3,300,000. It replaces Navistar 1882259C93, 1832094C92, 1832095C2, 1879745C93 and 1879747C2, and it took over from the earlier Alliant Power number AP63687. It comes with a new injection pressure regulator (IPR) valve, Alliant Power AP63513, and the fuel supply pump.
The injectors on these engines are fired by high-pressure oil, and this pump makes that pressure. When it wears, the engine cranks long, will not restart hot, stalls, or sets low injection control pressure (ICP) faults. Rule out oil leaks at the hose, the rail and the injector seals first. This is the 16cc pump for the MaxxForce 9 and MaxxForce 10. The MaxxForce DT takes the 12cc pump, AP63696.
Confirm Fitment Before You Order
Order by engine serial number, not by the number on your old pump: Navistar 1882259C93, 1832094C92 and 1832095C2 are also listed for the early-engine kit, AP63695. This pump covers 3,040,001 to 3,300,000. Engines from 3,000,001 to 3,040,000 take that kit, which adds the updated high-pressure hose and fitting, and engines from 3,300,001 take a different pump. Send us your engine serial number before you order. Call 530-668-0818 and we will confirm the exact match at no charge before anything ships.
Specifications
| Part number | AP63697 |
| Brand | Alliant Power |
| Condition | Remanufactured |
| Warranty | Alliant Power 24-month, unlimited-mileage warranty. |
| Type | High-pressure oil pump (HPOP), supplies the oil pressure that fires the injectors |
| Pump displacement | 16cc |
| Engines | International / Navistar MaxxForce 9 and MaxxForce 10 |
| Model years | 2007 to 2010 |
| Engine serial numbers | 3,040,001 through 3,300,000 |
| Included | New IPR valve (Alliant Power AP63513) and the fuel supply pump |
| Core charge | Refundable in full when we receive your rebuildable core |
| Shipping weight | 22 lb |
Fits / Applications
- International / Navistar MaxxForce 9 and MaxxForce 10, 2007 to 2010, engine serial 3,040,001 through 3,300,000
- 16cc pump. The MaxxForce DT takes the 12cc pump, AP63696.
- Not for engine serial 3,000,001 to 3,040,000. Those take the kit with the updated hose and fitting, AP63695.
- Not for engines from serial 3,300,001 (2010 and later) or for 2004 to 2006 DT570 and HT570 engines. Those take other pumps.
The pump comes with a new IPR valve and the fuel supply pump. It runs on engine oil, so fit it with clean oil and a new oil filter. Engines below serial 3,040,001 also need the updated high-pressure hose and fitting, which are not part of this pump.
Part Numbers & Cross Reference
Alliant Power AP63697 · Navistar 1882259C93 · Navistar 1832094C92 · Navistar 1832095C2 · Navistar 1879745C93 · Navistar 1879747C2 · Alliant Power, earlier number AP63687
Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.
Frequently Asked Questions
Will the AP63697 fit my MaxxForce 9 or MaxxForce 10?
It fits 2007 to 2010 MaxxForce 9 and MaxxForce 10 engines with serial numbers 3,040,001 through 3,300,000. Engines from 3,000,001 to 3,040,000 take the kit version, AP63695. Call 530-668-0818 with your engine serial number and we will confirm it.
What numbers does the AP63697 replace?
Navistar 1882259C93, 1832094C92, 1832095C2, 1879745C93 and 1879747C2. It also took over from the earlier Alliant Power number AP63687.
Is it new or remanufactured, and is there a core?
It is remanufactured by Alliant Power. A refundable core charge applies, and it is refunded in full when we receive your rebuildable old pump.
Is this the same pump as the MaxxForce DT pump?
No. The MaxxForce DT is listed for the 12cc pump, AP63696. The AP63697 is the 16cc pump for the MaxxForce 9 and MaxxForce 10, and it comes with a new IPR valve (Alliant Power AP63513) and the fuel supply pump.
