This is the Alliant Power AP63696, a 12cc high-pressure oil pump (HPOP) remanufactured by Alliant Power for the 2007 to 2010 International / Navistar MaxxForce DT, engine serial numbers 3,040,001 through 3,300,000. It replaces Navistar 1882258C93, 1832092C92, 1832093C2, 1879743C93 and 1879744C2, and it took over from the earlier Alliant Power number AP63686. It comes with a new injection pressure regulator (IPR) valve, Alliant Power AP63513, and the fuel supply pump.

The pump supplies the high-pressure oil that fires the injectors. Long cranking, a hot no-start, stalling and injection control pressure (ICP) that will not come up all point at the high-pressure oil system. Check for oil leaks at the hose, the rail and the injector seals before you replace the pump. This is the 12cc pump for the MaxxForce DT. The MaxxForce 9 and MaxxForce 10 take the 16cc pump, AP63697.

Specifications

Fits / Applications

• International / Navistar MaxxForce DT, 2007 to 2010, engine serial 3,040,001 through 3,300,000
• 12cc pump. The MaxxForce 9 and MaxxForce 10 take the 16cc pump, AP63697.
• Not for engine serial 3,000,001 to 3,040,000. Those take the kit with the updated hose and fitting, AP63694.
• Not for engines from serial 3,300,001 (2010 and later) or for 2004 to 2006 DT466 engines. Those take other pumps.

The pump comes with a new IPR valve and the fuel supply pump. It runs on engine oil, so fit it with clean oil and a new oil filter. Engines below serial 3,040,001 also need the updated high-pressure hose and fitting, which are not part of this pump.

Part Numbers & Cross Reference

Alliant Power AP63696  ·  Navistar 1882258C93  ·  Navistar 1832092C92  ·  Navistar 1832093C2  ·  Navistar 1879743C93  ·  Navistar 1879744C2  ·  Alliant Power, earlier number AP63686

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the AP63696 fit my MaxxForce DT?

It fits 2007 to 2010 MaxxForce DT engines with serial numbers 3,040,001 through 3,300,000. Engines from 3,000,001 to 3,040,000 take the kit version, AP63694. Call 530-668-0818 with your engine serial number and we will confirm it.

What numbers does the AP63696 replace?

Navistar 1882258C93, 1832092C92, 1832093C2, 1879743C93 and 1879744C2. It also took over from the earlier Alliant Power number AP63686.

Is it new or remanufactured, and is there a core?

It is remanufactured by Alliant Power. A refundable core charge applies, and it is refunded in full when we receive your rebuildable old pump.

What comes with the AP63696?

A new IPR valve (Alliant Power AP63513) and the fuel supply pump come with it. The updated hose and fitting that earlier engines need are not part of this pump.

Related Parts

• 2007-2010 International MaxxForce 9 & 10 16cc High-Pressure Oil Pump | Alliant Power AP63697 Remanufactured
• International MaxxForce DT G2.9 Fuel Injector | Alliant Power AP66918 Remanufactured (2007-2010, 210-300 hp)
• International DT466E & I530E HEUI Fuel Injector | Alliant Power AP63812BJ New (BJ/BG Code)
• International DT466E & I530E HEUI Injector Set of 6 | Alliant Power AP63812BJ New (BJ/BG Code)

Why Buy From Valley Fuel Injection

We are a diesel fuel-injection and turbocharger shop in Woodland, CA, rebuilding pumps, injectors and turbos on our own benches since 1993, not a drop-ship storefront. When you call, you talk to the people who test these units. We verify fitment against your engine serial, VIN or build date before anything ships, so the right part arrives the first time.
