Kubota 16062-51013 is a new, genuine Kubota 4-cylinder injection pump assembly. Kubota’s catalog lists it on B3000HSDC, B3030HSD, B3200HSD and B3300SUHSD tractors, the F3680 front mower, and the KX030-4 and KX71-3S excavators. It replaces 16062-51010, so it also covers older models built with that number, including the B2710HSD, B2910HSD, B7800HSD, KX71, KX71-3 and KX91-2. Most of these machines run the 4-cylinder Kubota V1505; the KX71-3S, for example, uses the V1505-BH.

Kubota lists other V1505 injection pumps too, such as 16060-51013, for different builds. The numbers look alike but they are different parts, so match the number on your old pump before you order.

Specifications

Fits / Applications

• Kubota B3000HSDC and B3000HSDCC tractors
• Kubota B3030HSD, B3200HSD, B3200HSDWO and B3300SUHSD tractors
• Kubota F3680 front mower
• Kubota KX030-4 excavator
• Kubota KX71-3S excavator, cab and canopy
• Older models first built with 16062-51010: B2710HSD, B2910HSD, B3030HSDC, B3030HSDCC and B7800HSD tractors
• Kubota KX71, KX71-3 and KX91-2 excavators, R310 and R310BH wheel loaders (old type) and F3060 mower (first built with 16062-51010)

Kubota sets injection timing on this style of pump with shims under the pump mounting flange. Keep the old shim stack, fit it under the new pump, then check timing to the Kubota workshop manual spec for your engine. When you fit the pump, use the stop lever to line up the governor fork with the pump’s control rack pin; a missed pin can damage the fork. Find out why the old pump failed, then flush the tank and lines and fit new filters before start-up.

Part Numbers & Cross Reference

Kubota (earlier number) 16062-51010

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Does Kubota 16062-51013 fit the B3030 and B3200?

Kubota’s catalog lists it on B3030HSD and B3200HSD tractors, along with the B3000HSDC and B3300SUHSD, the F3680 front mower and the KX030-4 and KX71-3S excavators. Most of these machines run the 4-cylinder Kubota V1505.

My old pump number is 16062-51010. Is 16062-51013 the replacement?

Yes. 16062-51013 replaces 16062-51010, so it also covers older models built with that number, including the B2710HSD, B2910HSD, B7800HSD, KX71, KX71-3 and KX91-2.

Is 16062-51013 the same pump as 16060-51013?

No. Kubota lists other V1505 injection pumps, such as 16060-51013, for different builds. The numbers look alike but they are different parts, so match the number on your old pump or call 530-668-0818 with the machine model and serial plus the engine serial.

Is 16062-51013 new, and do I send my old pump back?

It is a new genuine Kubota 4-cylinder injection pump assembly. There is no core charge and your old pump does not come back to us. As an authorized Kubota dealer we confirm fitment against your serial numbers at no charge before anything ships.
