This is a new, genuine Kubota alternator assembly, part number 1E994-64010. It is a 12 V, 40 A unit with a P terminal, and it is Kubota’s current number for alternators 16678-64010, 16678-64012, 16678-64013 and 16678-64014. Kubota engine parts dealers list it for some builds of the Super Mini D722, D902 and Z602, the 05 Series D905, D1005, D1105, D1305 and V1505, and the WG1605.

Kubota built these engines with a dynamo or with a 30 A, 40 A or 60 A alternator, so the engine model alone does not pick the part. This is the 40 A unit with the P terminal, the tap some machines use for a tachometer or hour meter signal. Before you condemn the old alternator, check charging voltage at its output with a good battery, then the belt, the plug and the grounds.

Specifications

Fits / Applications

• Kubota D1105, V1505, D905, D1005 and D1305 05 Series diesel engines
• Kubota D902, D722 and Z602 Super Mini diesel engines
• Kubota WG1605 engine
• Direct replacement for Kubota alternators 16678-64010, 16678-64012, 16678-64013 and 16678-64014
• Used on some builds of these engines, not all. Match the number on your old alternator.

Disconnect the battery first. Compare the pulley, mounting ears and plug with the old alternator before you bolt the new one on. Set belt tension, check pulley alignment, clean the ground path, and connect the P terminal wire if your harness has one.

Part Numbers & Cross Reference

Kubota 1E994-64010  ·  Kubota (superseded) 16678-64014  ·  Kubota (superseded) 16678-64013  ·  Kubota (superseded) 16678-64012  ·  Kubota (superseded) 16678-64010

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 1E994-64010 fit my Kubota D1105 or V1505?

It is listed for some builds of the D1105 and V1505, and for the D722, D902, D905, D1005, D1305, Z602 and WG1605. Those engines were also built with other alternators, so call 530-668-0818 with your engine model and serial number, or match the number on your old unit.

What numbers does the 1E994-64010 replace?

It is Kubota’s current number for 16678-64010, 16678-64012, 16678-64013 and 16678-64014.

Is the 1E994-64010 new or remanufactured?

New, genuine Kubota.

How is it different from the Kubota 1E998-64010?

Output. The 1E994-64010 is the 12 V 40 A alternator with a P terminal and replaces the 16678 series. The 1E998-64010 is the 12 V 60 A alternator and replaces the 16615 series. They are separate parts, so order by the number on your old alternator.
