Kubota D1703-M-DI Injection Pump for L2501, KX033-4 & U35-4 | Genuine Kubota 1G830-51012
This is a new, genuine Kubota injection pump assembly, part number 1G830-51012. It is the mechanical injection pump for the Kubota D1703-M-DI-E4, a 1.6 liter three-cylinder direct-injection diesel. Kubota’s parts catalog lists one pump number for the L2501 compact tractor in its 2WD, 4WD and HST versions and for the KX033-4 and U35-4 compact excavators.
There is no common rail on this engine, so the pump meters and times the fuel itself. Worn plungers show up as hard starting, low power, surging or fuel in the oil. Check for air in the fuel, a plugged filter and a sticking stop solenoid before you condemn the pump, since they cause the same complaints.
Confirm Fitment Before You Order
Kubota lists this pump for the L2501, KX033-4 and U35-4 only. Other D1703 engines and the four-cylinder L-Series tractors are not on Kubota’s list for it: the L4740-3, for example, uses 1G762-51012. Send us your machine model and serial number, the engine serial number and the number on your old pump. Call 530-668-0818 and we will confirm the exact match at no charge before anything ships.
Specifications
| Part number | 1G830-51012 |
| Brand | Kubota |
| Condition | New, genuine, in original packaging |
| Warranty | Kubota genuine parts warranty: 1 year against defects in materials or workmanship. |
| Type | Mechanical injection pump assembly, 3 cylinder, not common rail |
| Kubota description | ASSY PUMP,INJECTION |
| Engine | Kubota D1703-M-DI-E4: 3 cylinder, 1.647 L (100.47 cu in), direct injection |
| Cylinders | 3 |
| Timing adjustment | Shims under the pump (Kubota lists 0.20, 0.25 and 0.30 mm) |
| Shipping weight | 8 lb |
Fits / Applications
- Kubota D1703-M-DI-E4 three-cylinder direct-injection diesel engine (1.6 L)
- Kubota L2501 compact tractor: L2501F, L2501DT and L2501HST (catalog codes L2501F, L2501D and L2501H)
- Kubota KX033-4 compact excavator
- Kubota U35-4 compact excavator
The pump sits on shims that set injection timing, and Kubota’s parts list shows 0.20, 0.25 and 0.30 mm shims for these machines. Keep the old shims together, refit the same thickness with new ones and check timing against the Kubota workshop manual. Fit a new gasket on the fuel joint, bleed the fuel system before the first start and check the injection lines for leaks.
Part Numbers & Cross Reference
Kubota 1G830-51012
Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.
Frequently Asked Questions
Will the 1G830-51012 fit my Kubota L2501?
Yes. Kubota’s parts catalog lists it for the L2501 in 2WD, 4WD and HST versions, all with the D1703-M-DI-E4 engine. Call 530-668-0818 with the tractor serial number and we will confirm it before you order.
Does it fit the Kubota KX033-4 and U35-4?
Yes. Kubota lists the same pump number for both compact excavators.
How is injection timing set with this pump?
The pump sits on shims, and Kubota’s parts list shows 0.20, 0.25 and 0.30 mm shims for these machines. Keep the old shims with the engine and check timing against the Kubota workshop manual after fitting.
Is it new or remanufactured?
New, genuine Kubota.
Related Parts
- Kubota V2203-M & V2403-M Injection Pump for L4400, MX4700 & L4740-3 | Genuine Kubota 1G762-51012
- Kubota V2203-M Injection Pump 1G916-51013 (Genuine)
- Kubota V2003 & V2403-T Injection Pump for Bobcat S185, S205, T180, T190 | Bosch H104139414 New
- Kubota V2003-T & V2403-M-T Turbo Fuel Injector Kit for L5740, MX5100 & M5140 | Genuine Kubota 16419-53905
Why Buy From Valley Fuel Injection
We are an authorized Kubota dealer and a diesel fuel-injection shop in Woodland, CA, working on diesel engines since 1993. When you call, you talk to people who know Kubota engines, and we check the part number against your engine serial or machine model before anything ships, so the right part arrives the first time. See our Kubota engine sales, parts and service.
UPS Ground anywhere in the lower 48. Questions on fitment? Call 530-668-0818.
Pricing covers the unit itself. Any applicable sales tax is additional; shipping is calculated at checkout. Buying tax-exempt? Qualifying diesel repair shops, fleets, farms, and agricultural operations can purchase tax-free. Set up tax-exempt purchasing once and every qualifying order is tax-free going forward.
