This is a new, genuine Kubota starter motor, part number 17381-63012. It is a 12 V, 1.4 kW unit for Kubota 03 Series diesels. Kubota engine dealers list it for some builds of the D1403, D1503, D1703, V1903, V2003, V2203 and V2403, and for Kubota SQ-1140, SQ-1200, SQ-3170 and SQ-3250 diesel generators. It is Kubota’s replacement for starters 17381-63010 and 70000-65440.

Replace a starter when it clicks but will not turn, cranks slowly on a good battery, grinds on engagement, or pulls too much current. Rule out the battery, cables, grounds and the start signal first. Kubota built 03 Series engines with more than one starter, and the output and the pinion tooth count differ between them, so the engine model alone is not enough to order by.

Specifications

Fits / Applications

• Kubota 03 Series diesel engines that use the 12 V 1.4 kW starter 17381-63012
• Some builds of the Kubota D1403, D1503 and D1703
• Some builds of the Kubota V1903, V2003, V2203 and V2403
• Kubota SQ-1140, SQ-1200, SQ-3170 and SQ-3250 diesel generators
• Replaces Kubota starters 17381-63010 and 70000-65440

Disconnect the battery before removal. Before you fit the new starter, count the pinion teeth and compare the mounting flange and terminals with the old one. Clean the mounting face and the ground path, check the flywheel ring gear for worn or chipped teeth, and tighten the mounting bolts to Kubota’s torque spec.

Part Numbers & Cross Reference

Kubota 17381-63012  ·  Kubota (superseded) 17381-63010  ·  Kubota (superseded) 70000-65440

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 17381-63012 fit my Kubota V2203?

It is listed for some V2203 builds, not all of them. Kubota also fitted 12 V, 2.0 kW starters to 03 Series engines, and this one is 1.4 kW. Call 530-668-0818 with your engine serial number and the number on your old starter.

What numbers does the 17381-63012 replace?

It is Kubota’s replacement for starters 17381-63010 and 70000-65440.

How do I tell this starter from the other Kubota 03 Series starters?

Read the number on the old starter first. The 17381-63012 is rated 12 V, 1.4 kW, while 1K371-63010 and 17490-63014 are 2.0 kW starters. Count the pinion teeth on the old starter as well and tell us the count when you call.

Is this starter new or remanufactured?

New, genuine Kubota.
