Kubota D1803, V2203 & V2403 Mechanical Fuel Lift Pump (L, M & MX Series) | Genuine Kubota 17121-52033
Kubota 17121-52033 is the new, genuine Kubota mechanical fuel lift pump that Kubota describes as the fuel pump assembly for the 03 Series. Kubota engine dealers list it for the D1803, V2203 and V2403. Kubota’s tractor parts list puts it on a long run of L series tractors from the L2800 to the L5740, on the M4700, M4800SU, M4900, M5400, M5640SU and M5700, and on the MX4700, MX5000 and MX5100. It is the current number for the older 17121-52030.
Kubota’s description of this pump does not mention a primer. The 03 Series pump sold with a hand primer is a separate number, 17539-52033. A weak lift pump shows up as hard starting, surging, low power under load or stalling once warm, so check the fuel filter, the tank pickup and vent and the suction hose for air leaks before you replace it.
Confirm Fitment Before You Order
Kubota lists many of these same L and MX tractors with a second lift pump, 1G896-52030, so the tractor model alone does not settle it. Other 03 Series numbers are 17539-52033 with a hand primer and 1J801-52030 on the common-rail D1803-CR and V2403-CR. Send us the tractor or engine model, the serial number and the number on your old pump, and we will confirm the match before you order. Call 530-668-0818 and we will confirm the exact match at no charge before anything ships.
Specifications
| Part number | 17121-52033 |
| Brand | Kubota |
| Condition | New, genuine, in original packaging |
| Warranty | Kubota genuine parts warranty: 1 year against defects in materials or workmanship. |
| Type | Mechanical fuel lift pump, engine-driven |
| Engine series | Kubota 03 Series |
| Engines | D1803, V2203, V2403 |
| Machines | Many Kubota L, M and MX series tractors |
| Hand primer | Not mentioned in Kubota’s description. The pump with primer is 17539-52033 |
| Replaces | 17121-52030 |
| Shipping weight | 3 lb |
Fits / Applications
- Kubota D1803, V2203 and V2403 engines (some builds)
- Kubota L2800, L2900, L3000, L3010, L3130, L3240, L3300, L3400 and L3430 tractors
- Kubota L3540, L3600, L3700SU, L3710, L3830, L3940, L4200 and L4240 tractors
- Kubota L4300, L4310, L4330, L4350, L4400, L4610, L4630, L4740 and L4850 tractors
- Kubota L5030, L5040, L5240, L5450 and L5740 tractors
- Kubota M4700, M4800SU, M4900, M5400, M5640SU and M5700 tractors
- Kubota MX4700, MX5000 and MX5100 tractors
- Replaces Kubota fuel pump 17121-52030
- Common-rail D1803-CR and V2403-CR engines are listed with a different feed pump, 1J801-52030
Fit a new mounting gasket and make sure the pump’s drive sits squarely on the cam before you tighten the mounting bolts. Clamp both hoses, bleed the fuel system as the tractor or engine manual describes, and check for leaks.
Part Numbers & Cross Reference
Kubota 17121-52033 · Kubota (superseded) 17121-52030
Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.
Frequently Asked Questions
Will the 17121-52033 fit my Kubota L3400 or MX5100?
Kubota’s parts list shows this pump on both, but it also shows a second pump, 1G896-52030, on those tractors. Match the number on your old pump, or call 530-668-0818 with the tractor serial number.
What is the difference between 17121-52033 and 17539-52033?
They are separate Kubota numbers for 03 Series engines. Kubota describes 17539-52033 as the fuel pump assembly with primer, and its description of 17121-52033 does not mention a primer.
What number does the 17121-52033 replace?
It replaces Kubota 17121-52030.
Is the 17121-52033 new or remanufactured?
It is a new, genuine Kubota pump assembly.
