This is a new, genuine Kubota dynamo assembly, part number 15531-64017. It is a 12 V, 14 A permanent-magnet dynamo that charges through a separate regulator. Kubota engine dealers list it for the D722 and D1105 diesels and for the WG750, WG752 and DF752 engines. Kubota dealer catalogs list it for a long run of Kubota machines: ZD-series zero-turn mowers, BX sub-compact tractors, GR lawn and garden tractors, the B7410D, the K008 and K008-3 excavators and older B, F, G and KH models. It replaces six older Kubota dynamo numbers, including 15531-64016 and 15531-64013, and it crosses to Bobcat 6652721.

Replace the dynamo when the battery will not stay charged, the charge lamp stays on with the engine running, or the bearing is rough or noisy. The regulator is a separate part, so test it and check the plug and wiring first. A failed regulator gives the same no-charge complaint as a failed dynamo.

Specifications

Fits / Applications

• Kubota D722 and D1105 diesel engines
• Kubota WG750, WG752 and DF752 spark-ignition engines
• Kubota ZD18, ZD21, ZD28, ZD221, ZD25F, ZD321, ZD323, ZD326 and ZD331 zero-turn mowers
• Kubota ZD1011, ZD1021, ZD1211, ZG332 and ZP330 zero-turn mowers
• Kubota GR2100, GR2110, GR2120 and GR2120B lawn and garden tractors
• Kubota BX1500D, BX1800D, BX1830D, BX2200D, BX2230D, BX22D and BX23D tractors
• Kubota B7410D tractor and older B1550, B1750, B2150, B5200, B6200, B7200, B8200, B9200 and B20 models
• Kubota K008 and K008-3 excavators and KH-007H, KH-35, KH-36, KH-41, KH-51 and KH-61 excavators
• Kubota F2000, F2100E and GF1800 front mowers and the T1600H lawn tractor
• Kubota G1700, G1800, G1900, G2000, G3200, G4200, G5200H and G6200H lawn and garden tractors
• Direct replacement for dynamos numbered 15531-64010, 15531-64012, 15531-64013, 15531-64014, 15531-64015 and 15531-64016. Other dynamo and alternator numbers on these engines are different parts.

Disconnect the battery before you start. Check the drive belt for wear, set the belt tension and check pulley alignment. Make sure the dynamo plug, the regulator plug and the ground path are clean and tight. If the battery still does not charge with a good dynamo, test the regulator.

Part Numbers & Cross Reference

Kubota 15531-64017  ·  Kubota (superseded) 15531-64016  ·  Kubota (superseded) 15531-64015  ·  Kubota (superseded) 15531-64014  ·  Kubota (superseded) 15531-64013  ·  Kubota (superseded) 15531-64012  ·  Kubota (superseded) 15531-64010  ·  Kubota (superseded) KEARA-15531  ·  Bobcat 6652721

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 15531-64017 fit my Kubota ZD21 or BX2200?

Kubota dealer catalogs list it for the ZD18, ZD21 and ZD28 mowers and the BX1500D, BX1800D, BX2200D and BX2230D tractors, among many other Kubota machines. Call 530-668-0818 with your model and serial number and we will confirm it.

What numbers does the 15531-64017 replace?

It replaces Kubota 15531-64016, 15531-64015, 15531-64014, 15531-64013, 15531-64012 and 15531-64010, and Kubota’s KEARA-15531 number also leads to this part. It crosses to Bobcat 6652721. Bobcat 6686133 crosses to a different Kubota dynamo, 17531-64012.

What is the difference between the 15531-64017 and the 17531-64012?

Both are 14 A Kubota dynamos, and engine dealers list both for the D722 and D1105. Kubota dealer catalogs list Kubota tractors, mowers and excavators under 15531-64017 and none under 17531-64012. Kubota keeps them as separate part numbers, so order the number on your old dynamo or let us check your serial number.

Does this dynamo have a built-in regulator?

No. It is a permanent-magnet dynamo that charges through a separate regulator, so test the regulator and the wiring before you replace the dynamo.
