Kubota D722, D1105 & V1505 Engine Dynamo Assembly | Genuine Kubota 19269-64010
This is a new, genuine Kubota dynamo assembly, part number 19269-64010. Kubota engine dealers list it for the D722, D1105 and V1505 diesels. Kubota’s catalogs name it both “ASSY DYNAMO” and “ALTERNATOR ASSY”, and Kubota does not publish an output rating for it. It is a separate part number from the two 14 A dynamos, 15531-64017 and 17531-64012.
The usual reasons to replace a dynamo are a battery that will not stay charged, a charge lamp that stays on with the engine running, and a rough or noisy bearing. Rule out the belt, the plug, the wiring and the regulator in the charging circuit first.
Confirm Fitment Before You Order
Kubota lists several charging units for these engines: dynamos 15531-64017 and 17531-64012 (both 14 A), this dynamo, and the 12 V 60 A alternator 19630-64015. The engine model alone does not pick the part, and Kubota dealer catalogs show no Kubota tractor or mower under this number. Order 19269-64010 only if that number is on your old dynamo or in your parts book. Send us the engine model, the engine serial number and the number on your old dynamo. Call 530-668-0818 and we will confirm the exact match at no charge before anything ships.
Specifications
| Part number | 19269-64010 |
| Brand | Kubota |
| Condition | New, genuine, in original packaging |
| Warranty | Kubota genuine parts warranty: 1 year against defects in materials or workmanship. |
| Type | Dynamo assembly |
| Engines | Kubota D722, D1105 and V1505 |
| Kubota description | ASSY DYNAMO, also ALTERNATOR ASSY |
| Shipping weight | 2 lb |
Fits / Applications
- Kubota D722 diesel engine
- Kubota D1105 diesel engine
- Kubota V1505 diesel engine
- Direct replacement for a dynamo numbered 19269-64010. Other dynamo and alternator numbers on these engines are different parts.
Disconnect the battery before you start. Check the drive belt for wear, set the belt tension and check pulley alignment. Make sure the plug and the ground path are clean and tight. If the battery still does not charge, test the regulator and the wiring.
Part Numbers & Cross Reference
Kubota 19269-64010
Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.
Frequently Asked Questions
Will the 19269-64010 fit my Kubota D722, D1105 or V1505?
Kubota engine dealers list it for all three engines. They were also built with other dynamos and with alternators, so it is the right part only if your old dynamo or parts book shows 19269-64010.
Is the 19269-64010 the same as the 15531-64017 or the 17531-64012?
No. All three are genuine Kubota dynamos for small Kubota diesels, but they are separate part numbers and no catalog shows one replacing another. Order the number on your old dynamo.
What should I send you to confirm the fit?
The engine model, the engine serial number and the number on your old dynamo. Call 530-668-0818 and we will check it before you order.
Is this dynamo new or remanufactured?
It is a new, genuine Kubota dynamo assembly.
