This is a new, genuine Kubota starter motor, part number 19269-63010. It is a 12 V unit with a 9-tooth pinion, and Kubota’s parts description marks it as a Super Mini and 05 Series starter. Kubota engine dealers list it for the D722, D902, D905, D1105, V1305 and V1505. On machines it is listed for the Kubota BX1830D, BX1850D, BX1870, BX24D, BX25 and BX25DLB sub-compact tractors and the KX018-4 compact excavator.

Replace a starter when it clicks but will not turn, cranks slowly on a good battery, grinds on engagement, or pulls too much current. Rule out the battery, cables, grounds and the start signal first. Kubota sells several starters for these small engines, with different outputs, different pinions and 12 V or 24 V windings, so match the number on your old starter.

Specifications

Fits / Applications

• Kubota Super Mini and 05 Series diesel engines that use the 12 V 9-tooth starter 19269-63010
• Kubota Super Mini Series diesels: D722 and D902 (certain builds)
• Kubota 05 Series diesels: D905, D1105, V1305 and V1505 (certain builds)
• Kubota BX1830D, BX1850D and BX1870 sub-compact tractors
• Kubota BX24D, BX25 and BX25DLB sub-compact tractors
• Kubota KX018-4 compact excavator

Disconnect the battery before removal. Before you fit the new starter, count the pinion teeth and compare the mounting flange and terminals with the old one. Clean the mounting face and the ground path, check the flywheel ring gear for worn or chipped teeth, and tighten the mounting bolts to Kubota’s torque spec.

Part Numbers & Cross Reference

Kubota 19269-63010

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 19269-63010 fit my Kubota BX25?

It is listed for the BX25 and BX25DLB, along with the BX1830D, BX1850D, BX1870 and BX24D. For any other BX model, call 530-668-0818 with your tractor model and serial number.

Which Kubota engines take the 19269-63010?

Kubota engine dealers list it for the D722, D902, D905, D1105, V1305 and V1505. Not every build of those engines uses this starter, so check the number on your old one.

How is it different from the 37560-63010 and 16824-63013 starters?

They are three separate Kubota starters for small Kubota diesels. The 19269-63010 is 12 V with a 9-tooth pinion, and the 16824-63013 has an 8-tooth pinion. The 37560-63010 is a 12 V, 1.2 kW starter under its own number, so match the number on your old starter before you order.

Is this starter new or remanufactured?

New, genuine Kubota.
