Kubota D722 & D902 Stop Solenoid for K008-5, U10-5, KX018-4 & U17 Excavators | Genuine Kubota 1J022-60022
This is a new, genuine Kubota engine stop solenoid assembly, part number 1J022-60022. Kubota’s parts lists show it in the stop solenoid group of the K008-5, U10-5, KX018-4 and U17 mini excavators, and Kubota engine catalogs list this solenoid for the Super Mini Z482, D722 and D902 diesels. It is the current number: it replaces 1G820-60022 and 1J022-60020, and through them the older 1G820-60010 and 1G820-60012. Kubota also listed 1G820-60022 for the KX41-3, the U15 and the SCL1000.
This is not the 16851-60015 stop solenoid used on Kubota’s standard industrial Super Mini builds and the older K008-3. Both are SM series stop solenoids, but they are separate part numbers, so order by the number on the old part or by machine. A failed stop solenoid shows up as an engine that will not start, will not keep running or will not shut off, depending on how the machine is wired. Check the fuse, the wiring, the connector and the stop lever first.
Confirm Fitment Before You Order
Super Mini engines use more than one stop solenoid. This 1J022-60022 is the one in the K008-5, U10-5, KX018-4 and U17. The older K008-3 and Kubota’s standard industrial Z482, D722 and D902 builds take 16851-60015. Send us your machine model and serial number, or the engine model, the engine serial number and the number on the old solenoid. Call 530-668-0818 and we will confirm the exact match at no charge before anything ships.
Specifications
| Part number | 1J022-60022 |
| Brand | Kubota |
| Condition | New, genuine, in original packaging |
| Warranty | Kubota genuine parts warranty: 1 year against defects in materials or workmanship. |
| Type | Engine stop solenoid assembly |
| Kubota description | SOLENOID,ASSY(STOP) |
| Engine family | Kubota Super Mini (SM) series |
| Engines listed | Z482, D722, D902 |
| Replaces | 1G820-60022, 1J022-60020, 1G820-60012, 1G820-60010 |
| Shipping weight | 2 lb |
Fits / Applications
- Kubota K008-5 mini excavator (D722 engine)
- Kubota U10-5 mini excavator
- Kubota KX018-4 mini excavator
- Kubota U17 mini excavator
- Kubota KX41-3, U15 and SCL1000, which Kubota listed with the older 1G820-60022
- Kubota Super Mini diesel engines Z482, D722 and D902, on builds that call for this solenoid
- Direct replacement for Kubota 1G820-60022 and 1J022-60020
Kubota’s excavator parts lists show the solenoid with a separate stay, 1G820-60170, an O-ring, 04814-06310, and its bolts. Fit a new O-ring and check that the stop lever moves freely before you bolt the new solenoid on. If the old coil burned out, find the cause before you fit the new one.
Part Numbers & Cross Reference
Kubota 1J022-60022 · Kubota (superseded) 1J022-60020 · Kubota (superseded) 1G820-60022 · Kubota (superseded) 1G820-60012 · Kubota (superseded) 1G820-60010
Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.
Frequently Asked Questions
Will the 1J022-60022 fit my Kubota U17 or KX018-4?
Yes. Kubota’s parts lists show 1J022-60022 in the stop solenoid group of the U17 and the KX018-4, and also of the K008-5 and the U10-5.
My old solenoid says 1G820-60022. Is this the right part?
Yes. 1J022-60022 is Kubota’s current number and replaces both 1G820-60022 and 1J022-60020.
Is it the same as the 16851-60015 stop solenoid?
No. 16851-60015 is the stop solenoid on the older K008-3 and Kubota’s standard Super Mini engine builds. The K008-5, U10-5, KX018-4 and U17 take 1J022-60022. Call 530-668-0818 if you are not sure which one your engine has.
Is it new or remanufactured?
New, genuine Kubota.
