This is a new, genuine Kubota starter motor, part number 16285-63010. It is a 12 V, 1.2 kW unit with a 9-tooth pinion. Kubota engine dealers list it for some builds of the D722 and of the 05 Series engines: the D905, D1005, D1105, D1305, V1305 and V1505 diesels, plus the WG1605. It is also listed for the Kubota U15 compact excavator. It is Kubota’s replacement for starters 16271-63010 and 16285-63012.

Replace a starter when it clicks but will not turn, cranks slowly on a good battery, grinds on engagement, or pulls too much current. Rule out the battery, cables, grounds and the start signal first. Kubota built these engines with more than one starter. Two of them, this one and 37560-63010, are both 12 V, 1.2 kW, so the ratings alone will not tell them apart. Order by the number on your old starter.

Specifications

Fits / Applications

• Some builds of the Kubota D722 three-cylinder diesel
• Some builds of the Kubota D905, D1005, D1105 and D1305 three-cylinder diesels
• Some builds of the Kubota V1305 and V1505 four-cylinder diesels
• Kubota WG1605 engine (some builds)
• Kubota U15 compact excavator
• Replaces Kubota starters 16271-63010 and 16285-63012

Disconnect the battery before removal. Before you fit the new starter, count the pinion teeth and compare the mounting flange and terminals with the old one. Clean the mounting face and the ground path, check the flywheel ring gear for worn or chipped teeth, and tighten the mounting bolts to Kubota’s torque spec.

Part Numbers & Cross Reference

Kubota 16285-63010  ·  Kubota (superseded) 16271-63010  ·  Kubota (superseded) 16285-63012

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 16285-63010 fit my Kubota D1105?

It is listed for some D1105 builds, not all of them. Kubota fitted several starters to the D1105, including 37560-63010 with the same 1.2 kW rating. Call 530-668-0818 with your engine serial number and the number on your old starter.

What numbers does the 16285-63010 replace?

It is Kubota’s replacement for starters 16271-63010 and 16285-63012.

How is the 16285-63010 different from the 16235-63010?

The 16285-63010 is 1.2 kW with a 9-tooth pinion. The 16235-63010 is 1.4 kW with a 13-tooth pinion. Count the teeth on your old starter before you order.

Is this starter new or remanufactured?

New, genuine Kubota.
