This is a new, genuine Kubota alternator assembly, part number 1E998-64010, rated 12 V and 60 A. It is Kubota’s current number for the 16615 series alternators: 16615-64010, 16615-64012, 16615-64013, 16615-64014 and 16615-64015. Kubota engine parts dealers list it for the D902, D1005, D1105 and V1505 diesels, and Kubota’s own application note for the 16615 alternator reads newer WG972, Super Mini and 05 Series engines.

Kubota sells more than one 12 V 60 A alternator for its small engines, and it built the same engines with 30 A and 40 A units too. Order by the number on the alternator you are taking off. If the charge light is on or the battery will not hold up, test output at the alternator with a good battery and check the belt and wiring first.

Specifications

Fits / Applications

• Kubota D902 diesel engine (Super Mini)
• Kubota D1005, D1105 and V1505 diesel engines (05 Series)
• Newer Kubota WG972 engine builds
• Direct replacement for Kubota alternators 16615-64010, 16615-64012, 16615-64013, 16615-64014 and 16615-64015
• Used on some builds of these engines, not all. Match the number on your old alternator.

Disconnect the battery first. Compare the pulley, mounting ears and plug with the old alternator before you bolt the new one on. Set belt tension, check pulley alignment and clean the ground path. If the old alternator was a lower-output unit, check that the charge wire and fuse are sized for 60 A.

Part Numbers & Cross Reference

Kubota 1E998-64010  ·  Kubota (superseded) 16615-64015  ·  Kubota (superseded) 16615-64014  ·  Kubota (superseded) 16615-64013  ·  Kubota (superseded) 16615-64012  ·  Kubota (superseded) 16615-64010

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 1E998-64010 fit my Kubota D1105 or V1505?

It is listed for the D902, D1005, D1105 and V1505. Those engines were also built with 30 A and 40 A alternators and with other 60 A units, so call 530-668-0818 with your engine model and serial number, or match the number on your old alternator.

What numbers does the 1E998-64010 replace?

It is Kubota’s current number for the 16615 series: 16615-64010, 16615-64012, 16615-64013, 16615-64014 and 16615-64015.

Is the 1E998-64010 new or remanufactured?

New, genuine Kubota.

Is it the same as the Kubota 19630-64015 or 1EA10-64010?

No. All three are 12 V 60 A Kubota alternators, but they are separate part numbers. Order by the number on your old alternator, or call 530-668-0818 with your engine serial number.
