This is a new, genuine Kubota engine stop solenoid assembly, part number 16271-60013. Kubota engine catalogs list it for the D905, D1005, D1105 and V1505 diesels, and Kubota’s machine parts lists show it in the stop solenoid group of the BX2680 tractor and the ZD1211 zero-turn mowers. It is also Kubota’s replacement for 16271-60012 and 16271-60010, the solenoid on BX23D, BX2660D and BX2670 tractors, ZD28, ZD326 and ZD331 mowers, F2400, FZ2100 and FZ2400 front mowers, the old type R310 wheel loader and KX41-2, KX41H, KX61-2, KX71 and KX91-2 excavators. It is a 12 V part.

Kubota’s small diesels were built with more than one stop solenoid, and they are separate parts. Kubota’s industrial engine parts lists for the D1005, D1105, D1305 and V1505 show 17208-60016, which is also the solenoid on the KX71-3S, KX030-4, U25S and U27-4 excavators, and the B3350, F3990 and ZD1511 take 1E366-60012. This 16271-60013 is the one on the machines named above. A failed stop solenoid shows up as an engine that will not start, will not keep running or will not shut off, depending on how the machine is wired. Check the fuse, the wiring, the connector and the stop lever before you replace it.

Specifications

Fits / Applications

• Kubota D905, D1005, D1105 and V1505 diesel engines, on builds that call for 16271-60013 or the older 16271-60012
• Kubota BX-series tractors: BX23D, BX2660D, BX2670, BX2680 and BX2680-1
• Kubota ZD zero-turn mowers: ZD28, ZD28F, ZD326P, ZD326S, ZD331P, ZD331LP and the ZD1211 (ZD1211, ZD1211L, ZD1211R, ZD1211RL and the -3 versions)
• Kubota front mowers: F2400, FZ2100, FZ2400
• Kubota excavators: KX41-2, KX41H, KX61-2, KX71, KX91-2
• Kubota R310 and R310BH wheel loaders, old type
• Direct replacement for Kubota 16271-60012 and 16271-60010
• Kubota’s industrial D1005, D1105, D1305 and V1505 builds and the KX71-3S, KX030-4, U25S and U27-4 excavators are listed with 17208-60016 instead

Kubota’s parts lists show the mounting hardware as separate parts: hex socket head bolt 01311-10612 on the BX2680 and ZD1211, and on older machines such as the KX41-2 and KX91-2 a solenoid cover gasket, 16299-60150. Compare the connector and the plunger of the new solenoid with the old one before you fit it. If the old coil burned out, find the cause first: a sticking stop lever, a bad relay or damaged wiring will take out the new one too.

Part Numbers & Cross Reference

Kubota 16271-60013  ·  Kubota (superseded) 16271-60012  ·  Kubota (superseded) 16271-60010

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 16271-60013 fit my Kubota BX2680 or ZD1211?

Yes. Kubota’s parts lists show 16271-60013 in the stop solenoid group of the BX2680 and BX2680-1 tractors and of the ZD1211 zero-turn mowers.

What numbers does the 16271-60013 replace?

Kubota 16271-60012 and the earlier 16271-60010. If your old solenoid or your parts book shows either number, this is the current part.

Is this the same solenoid as 17208-60016?

No. Kubota lists them for different builds: 17208-60016 for industrial D1005, D1105, D1305 and V1505 engines and excavators such as the KX71-3S and U27-4, and 16271-60013 for the machines listed here, such as the BX2680, ZD1211 and KX91-2. Call 530-668-0818 with your engine serial number if you are not sure.

Is it new or remanufactured?

New, genuine Kubota.
