This is a new, genuine Kubota radiator assembly, part number EG652-72060. Kubota engine dealers list it for the DF752, Kubota’s small dual-fuel spark-ignition engine that runs on gasoline or LPG. It is not the only radiator for the 750 and 752 gas engines. Kubota’s 12691-72060 is the radiator assembly for the DF and WG 750 and 752 Series, and 1G958-72062 is listed for the WG752 along with the Z482 and D722 diesels. EG652-72060 is a separate part number from both.

Kubota dealer catalogs do not show how these radiators differ, so the engine model alone will not tell you which one you have. Match the part number on the old radiator, or send us the engine serial number, before you order. Radiators are replaced for leaking tubes or seams, blocked fins, cracked tanks and broken mounts.

Specifications

Fits / Applications

• Kubota DF752 dual-fuel (gasoline and LPG) spark-ignition engine
• Direct replacement for a radiator numbered EG652-72060. Other radiator numbers on the 750 and 752 engines are different parts.

Before you drain the system, set the new radiator next to the old one and compare the hose necks, mounts, filler neck and shroud mounting points. Flush the system and refill with the coolant type and mix Kubota specifies for the engine. Replace soft or cracked hoses and weak clamps, and bleed trapped air before putting the machine back to work. If the engine is in a lift or other machine, the radiator cap, shroud, cushions and supports often carry the machine maker’s own part numbers, so check those pieces on the old unit before you start.

Part Numbers & Cross Reference

Kubota EG652-72060

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the EG652-72060 fit my Kubota DF752?

Kubota engine dealers list it for the DF752. Other radiators were used on the 750 and 752 engines too, such as 12691-72060, so it is the right part only if your old radiator or parts book shows EG652-72060.

Is EG652-72060 the same radiator as 12691-72060?

No. They are separate Kubota part numbers, and no catalog shows one replacing the other. 12691-72060 is Kubota’s radiator assembly for the DF and WG 750 and 752 Series, so order the number on your old radiator.

My DF752 is in a lift or other machine. What should I send you?

The machine’s make, model and serial number, the engine serial number and the number on the old radiator. Machine makers often list the radiator under their own part number, so call 530-668-0818 and we will check it before you order.

Is it new or remanufactured?

New, genuine Kubota.
