Kubota V3300 & V3800 (V3 Series) Starter Motor, 12V 2.5 kW 9-Tooth | Genuine Kubota 1C010-63015
This is a new, genuine Kubota starter motor, part number 1C010-63015. It is a 12 V, 2.5 kW unit with a 9-tooth pinion for Kubota V3 Series diesels, and it is listed for the V3300 and V3800. Kubota’s workshop manual for the V3300-E2B gives the same 12 V, 2.5 kW rating for that engine’s starting motor. It is Kubota’s current replacement for starters 1C010-63010, 1C010-63013 and 1C010-63014.
Replace a starter when it clicks but will not turn, cranks slowly on a good battery, grinds on engagement, or pulls too much current. Rule out the battery, cables, grounds and the start signal first. V3 Series engines were also built with other starters, including a 3.0 kW unit, so check the system voltage and the number on your old starter before you order.
Confirm Fitment Before You Order
Kubota V3 Series engines use more than one starter. This is the 12 V, 2.5 kW starter with a 9-tooth pinion. Kubota also lists a 12 V, 3.0 kW starter, 1K012-63013, for the V3300, V3600 and V3800, and the 1G772 starters for 07 Series engines carry the same 2.5 kW rating under separate part numbers. Send us your engine or tractor model, the engine serial number and the number on your old starter. Call 530-668-0818 and we will confirm the exact match at no charge before anything ships.
Specifications
| Part number | 1C010-63015 |
| Brand | Kubota |
| Condition | New, genuine, in original packaging |
| Warranty | Kubota genuine parts warranty: 1 year against defects in materials or workmanship. |
| Type | Starter motor |
| Voltage | 12 V |
| Output | 2.5 kW |
| Pinion teeth | 9 |
| Engine family | Kubota V3 Series |
| Replaces | 1C010-63010, 1C010-63013, 1C010-63014 |
| Shipping weight | 14 lb |
Fits / Applications
- Kubota V3 Series diesel engines that use the 12 V 2.5 kW 9-tooth starter
- Kubota V3300 (certain builds)
- Kubota V3800 (certain builds)
- Replaces Kubota starters 1C010-63010, 1C010-63013 and 1C010-63014
Disconnect the battery before removal. Before you fit the new starter, count the pinion teeth and compare the mounting flange and terminals with the old one. Clean the mounting face and the ground path, check the flywheel ring gear for worn or chipped teeth, and tighten the mounting bolts to Kubota’s torque spec.
Part Numbers & Cross Reference
Kubota 1C010-63015 · Kubota (superseded) 1C010-63014 · Kubota (superseded) 1C010-63013 · Kubota (superseded) 1C010-63010
Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.
Frequently Asked Questions
Will the 1C010-63015 fit my Kubota V3800?
It is listed for the V3300 and V3800, but V3 Series engines were built with more than one starter. This one is 12 V, 2.5 kW with a 9-tooth pinion. Call 530-668-0818 with your engine serial number and the number on your old starter.
What numbers does the 1C010-63015 replace?
Kubota starters 1C010-63010, 1C010-63013 and 1C010-63014.
How is it different from the 1K012-63013 starter?
Both are 12 V starters for V3 Series engines. The 1C010-63015 is rated 2.5 kW and the 1K012-63013 is rated 3.0 kW, and Kubota keeps them as separate part numbers, so match the number on your old starter.
Is this starter new or remanufactured?
New, genuine Kubota.
Related Parts
- Kubota V3800 New Complete Common-Rail Engine, SVL90-2 / SVL95-2s Repower (Genuine)
- Kubota V3307 V3800 SCV Suction Control Valve Kit 1J500-50550 (Genuine)
- Kubota V3800 Common Rail Fuel Injector Kit 1J500-53076 (Genuine)
- Kubota V3800 Common Rail Assembly 1J508-50602 (Genuine)
Why Buy From Valley Fuel Injection
We are an authorized Kubota dealer and a diesel fuel-injection shop in Woodland, CA, working on diesel engines since 1993. When you call, you talk to people who know Kubota engines, and we check the part number against your engine serial or machine model before anything ships, so the right part arrives the first time. See our Kubota engine sales, parts and service.
UPS Ground anywhere in the lower 48. Questions on fitment? Call 530-668-0818.
Pricing covers the unit itself. Any applicable sales tax is additional; shipping is calculated at checkout. Buying tax-exempt? Qualifying diesel repair shops, fleets, farms, and agricultural operations can purchase tax-free. Set up tax-exempt purchasing once and every qualifying order is tax-free going forward.
