Kubota D905, D1005, D1105, V1505 & RTV1100 Mechanical Fuel Lift Pump | Genuine Kubota 16285-52033
Kubota 16285-52033 is the new, genuine Kubota mechanical fuel lift pump for the 05 Series diesels. Kubota engine dealers list it for the D905, D1005, D1105, D1305, V1305 and V1505, and Kubota’s parts list puts it on the RTV1100 (CR and CW models) and the RTV1140CPX. It is the current number for the older 16285-52032 and 16285-52030, so it is the one to order if your old pump carries either of those.
When this pump gets weak the injection pump runs short of fuel: hard starting, hunting at idle, loss of power under load or stalling after warm-up. Check the fuel filter, the tank vent and the suction hose for air leaks first. If the pump leaks fuel or cannot pull fuel from the tank, replace it.
Confirm Fitment Before You Order
Not every 05 Series engine takes this pump. The RTV-X1100C, RTV-X1120D and RTV-X1140 use 1G910-52033, and Kubota lists that second pump on the RTV1100CR9, RTV1100CW9 and RTV1140CPX as well, so the model alone does not settle it. Some builds run a 12 V electric lift pump instead, and the D902 in the RTV900 uses 1G961-52030. Send us the engine or RTV model, the serial number and the number on your old pump, and we will confirm the match before you order. Call 530-668-0818 and we will confirm the exact match at no charge before anything ships.
Specifications
| Part number | 16285-52033 |
| Brand | Kubota |
| Condition | New, genuine, in original packaging |
| Warranty | Kubota genuine parts warranty: 1 year against defects in materials or workmanship. |
| Type | Mechanical fuel lift pump, engine-driven |
| Engine series | Kubota 05 Series |
| Engines | D905, D1005, D1105, D1305, V1305, V1505 |
| Machines | Kubota RTV1100 (CR and CW models) and RTV1140CPX |
| Replaces | 16285-52032, 16285-52030 |
| Shipping weight | 3 lb |
Fits / Applications
- Kubota D905, D1005 and D1105 engines
- Kubota D1305, V1305 and V1505 engines
- Kubota RTV1100CR, RTV1100CR9, RTV1100CRX, RTV1100CW, RTV1100CW9 and RTV1100CWX
- Kubota RTV1140CPX and RTV1140CPXR
- Replaces Kubota fuel pumps 16285-52032 and 16285-52030
- Some builds of these engines use a different lift pump, so match the number on your old pump
Fit a new mounting gasket and make sure the pump’s drive sits squarely on the cam before you tighten the mounting bolts. Clamp both hoses, bleed the fuel system as the engine or machine manual describes, and check for leaks.
Part Numbers & Cross Reference
Kubota 16285-52033 · Kubota (superseded) 16285-52032 · Kubota (superseded) 16285-52030
Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.
Frequently Asked Questions
Will the 16285-52033 fit my Kubota RTV1100?
Kubota’s parts list puts this pump on the RTV1100CR and RTV1100CW models and on the RTV1140CPX. The RTV1100CR9, RTV1100CW9 and RTV1140CPX are also listed with a second pump, 1G910-52033, so match the number on your old pump or call 530-668-0818 with the serial number.
Which engines is the 16285-52033 listed for?
Kubota engine dealers list it for the D905, D1005, D1105, D1305, V1305 and V1505. The larger 03 Series engines, such as the V2203 and V2403, take other pumps like 17121-52033 and 17539-52033.
What numbers does the 16285-52033 replace?
It replaces Kubota 16285-52032 and 16285-52030.
Is the 16285-52033 new or remanufactured?
New, genuine Kubota. It is a complete pump assembly, not a rebuilt one.
