This is a new, genuine Kubota injection pump assembly, part number 1G762-51012. Kubota describes it as a four-cylinder 03 Series pump, and it is the current number for the older 1G762-51010. Kubota’s parts catalog lists it for three tractors: L4400DT and L4400F models with the 2.2 liter V2203-M, the MX4700 (DT, F and H) with the 2.4 liter V2403-M, and the L4740-3 (GST, HST and HSTC), also a 2.4 liter. Kubota engine dealers file it under the V2203.

These are indirect-injection engines, and Kubota’s workshop manual lists their pump as a Denso PFR 4M type mini pump. It has no camshaft or governor of its own: the engine’s fuel camshaft drives it, and timing is set with shims under the pump. Typical reasons to replace it are worn plungers that no longer hold pressure, hard starting, low power or fuel in the oil. Rule out air in the fuel, a plugged filter and tired injectors first. The L4400 was built with two different pumps, this one and 1G916-51013, so check the number on the pump you are taking off.

Specifications

Fits / Applications

• Kubota V2203-M and V2403-M four-cylinder diesel engines (03-M Series, indirect injection)
• Kubota L4400DT and L4400F tractors, 2.2 L V2203-M. Kubota also lists pump 1G916-51013 for the L4400, so match the number on your old pump.
• Kubota MX4700DT, MX4700F and MX4700H tractors, 2.4 L V2403-M
• Kubota L4740GST-3, L4740HST-3 and L4740HSTC-3 tractors, 2.4 L
• Replaces Kubota injection pump 1G762-51010

Keep the shims from under the old pump together and refit the same number and thickness, then check injection timing against the Kubota workshop manual for your tractor. Kubota lists 0.20, 0.25 and 0.30 mm pump shims for these tractors. Fit new gaskets on the fuel joint, keep dirt out of the open fuel ports and bleed the fuel system before the first start.

Part Numbers & Cross Reference

Kubota 1G762-51012  ·  Kubota (superseded) 1G762-51010

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 1G762-51012 fit my Kubota L4400?

Kubota lists it for the L4400DT and L4400F, but it also lists a second pump, 1G916-51013, for the L4400. Call 530-668-0818 with your engine serial number or the number on your old pump before you order.

Does it replace the 1G762-51010?

Yes. 1G762-51010 is the older number, and Kubota’s parts list shows both numbers at the same position on the MX4700, L4740-3 and L4400.

What is the difference between 1G762-51012 and 1G916-51013?

They are two separate Kubota injection pumps for 03-M Series four-cylinder engines. Kubota lists 1G762-51012 for the MX4700, the L4740-3 and the L4400DT and L4400F, and 1G916-51013 for the L4600, L45 and R520S. Both numbers appear on the L4400, so the number on your old pump decides.

Is it new or remanufactured?

New, genuine Kubota.
