This is a new, genuine Kubota nozzle holder assembly, part number 1J730-53002. Kubota calls a complete mechanical injector an ASSY HOLDER, NOZZLE, so this is the whole injector, not a nozzle tip alone. It is for the Kubota V2607-DI, the naturally aspirated 2.6 liter four-cylinder direct-injection diesel with a mechanical in-line injection pump. Kubota’s parts lists put it on the U55 and on the KX057-4 compact excavator, where the engine group is marked V2607-DI-E3-BH.

The KX057-4 was built with two fuel systems. Machines with the mechanical V2607-DI take this injector. Machines with the common-rail V2607-CR take an electronic injector kit from the 1J706 series, and so does the U55-4. Hard starting, a rough idle, smoke or fuel knock point at tired injectors, but check the fuel filter and look for air in the supply side first. The engine takes four.

Specifications

Fits / Applications

• Kubota U55 compact excavator (mechanical V2607-DI engine)
• Kubota KX057-4 compact excavator, machines built with the mechanical V2607-DI engine (Kubota parts list: V2607-DI-E3-BH)
• Kubota V2607-DI naturally aspirated direct-injection diesel, four injectors per engine
• Not for the U55-4 or for KX057-4 machines with the common-rail V2607-CR, which take a 1J706 series injector kit
• Not for the turbocharged V2607-DI-T, which takes 1J700-53002

Set the new injector next to the old one before you fit it and compare the body, the fuel connections and any seal on the holder. Kubota’s parts list for these machines shows two O-rings and a packing with each nozzle holder as separate parts, so fit new ones. Kubota’s service data for the mechanical V2607 gives 9.81 to 11.2 N-m (7.24 to 8.26 lb-ft) for the overflow pipe joint screws and 22.5 to 36.2 N-m (16.6 to 26.6 lb-ft) for the injection pipe retaining nuts. Bleed the fuel system before cranking.

Part Numbers & Cross Reference

Kubota 1J730-53002

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will 1J730-53002 fit my Kubota KX057-4?

Only if the machine has the mechanical V2607-DI engine. KX057-4 machines with the common-rail V2607-CR take an electronic injector kit from the 1J706 series. Call 530-668-0818 with the machine serial number and we will check it.

Does it fit the Kubota U55 and the U55-4?

Kubota dealer catalogs list it for the U55. The U55-4 has the common-rail engine and takes a 1J706 series injector kit, not this nozzle holder.

Is 1J730-53002 the same as 1J700-53002?

No. 1J700-53002 is the nozzle holder for the turbocharged V2607-DI-T, the one Bobcat sells as 7020613. 1J730-53002 is for the non-turbo V2607-DI. Kubota lists them as separate parts.

Is it new or remanufactured?

New, genuine Kubota. It is the complete injector, which Kubota calls a nozzle holder assembly, not a nozzle tip alone.
