Kubota 17539-52033 is the new, genuine Kubota mechanical fuel lift pump that Kubota describes as the fuel pump assembly with primer. Kubota engine dealers list it for the 03 Series D1503, D1703, V2003, V2203 and V2403. It is the current number for the older 17539-52030, and it mounts with gasket 1G751-52140, which is sold separately.

The hand primer lets you fill the filter and bleed the low-pressure side without cranking the engine. A failing pump causes hard starting, surging, loss of power under load or stalling once warm. Check the filter, the tank vent and the suction hose for air leaks before you replace it.

Specifications

Fits / Applications

• Kubota D1503 and D1703 engines (some builds)
• Kubota V2003, V2203 and V2403 engines (some builds)
• Replaces Kubota fuel pump 17539-52030
• Mounts with Kubota gasket 1G751-52140

Fit a new 1G751-52140 mounting gasket and make sure the pump’s drive sits squarely on the cam before you tighten the mounting bolts. Use the hand primer to fill the filter and bleed the low-pressure side, then check both hoses for leaks.

Part Numbers & Cross Reference

Kubota 17539-52033  ·  Kubota (superseded) 17539-52030  ·  Kubota mounting gasket 1G751-52140

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

Will the 17539-52033 fit my Kubota V2203?

Kubota engine dealers list it for the D1503, D1703, V2003, V2203 and V2403. The V2203 has used other lift pumps too, so match the number on your old pump or call 530-668-0818 with the engine serial number.

Does the 17539-52033 have a hand primer?

Yes. Kubota describes it as the fuel pump assembly with primer. The 03 Series pump 17121-52033 is a separate number, and its description does not mention a primer.

What number does it replace, and which gasket does it use?

It replaces Kubota 17539-52030. Two Kubota engine dealer catalogs pair it with mounting gasket 1G751-52140, which is sold separately.

Is the 17539-52033 new or remanufactured?

New, genuine Kubota. It is a complete pump assembly with its hand primer.
