This is a new, genuine Kubota fuel injector, part number 16871-53002. Kubota calls it a nozzle holder assembly (HOLDER,NOZZLE,ASSY). It is the complete injector, with the holder body, spring, push rod and nozzle assembled and set. It fits Kubota’s Super Mini indirect-injection diesels: the three-cylinder D722 and D902 and the two-cylinder Z482 and Z602. Kubota lists it on the BX1870, BX1880, BX2370, BX2380, BX23S and BX25D tractors, the RTV-X900 and RTV900 XT, the GR2120, the ZD1011 and ZD1021 and the K008-5, KX018-4 and U10-5 excavators. It replaces 16871-53000.

Kubota sells this injector two ways. 16871-53002 is the injector on its own, and 16871-53904 is Kubota’s kit number for the same injector. Plan on a new copper gasket and heat seal for each one. Kubota also used a second injector family on the Super Mini engines, the 16001 series (16001-53904), mostly on earlier machines. Models built across the change, such as the BX1860, BX2360, BX25, RTV900 9 series, GR2110, ZD221, ZD321, ZD323, K008-3, KX41-3 and U17, are on Kubota’s lists for both families. Match the number on your old injector or send us the engine serial number.

Specifications

Fits / Applications

• Kubota D722 and D902 three-cylinder diesel engines
• Kubota Z482 and Z602 two-cylinder diesel engines
• Kubota BX1870, BX1880, BX2370, BX2380, BX23S and BX25D tractors
• Kubota RTV-X900 and RTV900 XT utility vehicles
• Kubota GR2120 garden tractor and ZD1011 and ZD1021 zero-turn mowers
• Kubota K008-5, KX018-4 and U10-5 excavators
• Kubota SCL1000 stand-on compact loader
• Kubota BX1860, BX2360, BX25, RTV900 9 series, GR2110, ZD221, ZD321, ZD323, K008-3, KX41-3 and U17: this injector or the 16001 series, depending on the engine
• Kubota GL11000-USA parts book: listed from serial 4DA0001. Before that the book lists 16001-53002.
• Kubota GL7000-USA parts book: listed from serial 4DA0001. Before that the book lists 16001-53002.
• On the other side of a serial break? Send us the serial number and we will check which part number Kubota calls for.

This is the injector on its own. Fit a new copper gasket and heat seal under each one: Kubota’s Super Mini workshop manual says both must be changed whenever an injector is removed, and Kubota’s numbers for them on these engines are 15841-53622 (gasket) and 19077-53650 (heat seal). Tighten the nozzle holder assembly to 49 to 68 Nm (37 to 50 ft-lb), bleed the fuel system and check the injection pipes and the overflow pipe for leaks.

Part Numbers & Cross Reference

Kubota 16871-53002  ·  Kubota (superseded) 16871-53000  ·  Kubota (kit number for the same injector) 16871-53904

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

What is the difference between 16871-53002 and 16871-53904?

They are the same injector. 16871-53002 is the nozzle holder assembly on its own, and 16871-53904 is Kubota’s kit number for it.

Will the 16871-53002 fit my Kubota BX2370, BX2380 or RTV-X900?

Kubota lists 16871-53002 for the BX2370, BX2380 and RTV-X900, along with the BX1870, BX1880, BX23S and BX25D. The three-cylinder engines take three. Call 530-668-0818 with your engine serial number if you want us to confirm before you order.

Does it replace 16001-53904?

No. The 16001 series is a different injector family that Kubota lists mostly for earlier Super Mini machines. They are separate part numbers, so match the number on your old injector or send us the engine serial number.

What does the 16871-53002 replace, and is it new?

It replaces Kubota 16871-53000. It is new, genuine Kubota.
