This is a new, genuine Kubota nozzle holder assembly, part number 1J700-53002. Kubota calls a complete mechanical injector an ASSY HOLDER, NOZZLE, so this is the whole injector, not a nozzle tip alone. It is for the Kubota V2607-DI-T, the turbocharged 2.6 liter four-cylinder direct-injection diesel that is fed by a mechanical in-line injection pump, and Kubota’s parts list for that engine shows four per engine. Bobcat sells the same injector as 7020613 for its machines built with this engine. It is Kubota’s replacement for the earlier holder 1J700-53000, with one condition: on engines built with the old holder it goes on together with new overflow pipe joint bolts.

Worn injectors on these engines show up as hard starting, a rough idle, a miss, white or black smoke, fuel knock or fuel in the oil. Check the fuel filter, look for air in the supply side and rule out the injection pump before you condemn the injectors. The engine takes four, so test all four before you replace one.

Specifications

Fits / Applications

• Kubota V2607-DI-T turbocharged direct-injection diesel with the mechanical in-line pump (Kubota parts list: V2607-DI-T-E3B)
• Four injectors per engine
• Bobcat machines built with that engine, where the Bobcat parts book calls for injector 7020613
• Engines built with the earlier 1J700-53000 holder: order it together with overflow pipe joint bolt 1C020-95810, as Kubota’s parts list says
• Not for the non-turbo V2607-DI in the Kubota KX057-4 and U55, which takes 1J730-53002
• Not for common-rail V2607-CR engines, which take electronic injector kits

Set the new injector next to the old one before you fit it, and compare the body, the overflow pipe connection and any dust seal on the holder. Kubota’s parts list shows two O-rings and a packing with each nozzle holder as separate parts, so fit new ones. Engines built with the older 1J700-53000 holder used an eye bolt on the overflow pipe at each injector. The new holder takes joint bolt 1C020-95810 there, and Kubota says to order holder and bolt as a set. Kubota’s service data for the mechanical V2607 gives 9.81 to 11.2 N-m (7.24 to 8.26 lb-ft) for the overflow pipe joint screws and 22.5 to 36.2 N-m (16.6 to 26.6 lb-ft) for the injection pipe retaining nuts. Bleed the fuel system before cranking.

Part Numbers & Cross Reference

Kubota 1J700-53002  ·  Kubota (superseded) 1J700-53000  ·  Bobcat 7020613

Cross-reference numbers can change with engine serial, build year and emissions tier, so treat this list as a starting point. Send us your engine serial number and we will confirm the exact match against your build before anything ships. That check is free and takes a few minutes.

Frequently Asked Questions

What engine does the Kubota 1J700-53002 injector fit?

The turbocharged Kubota V2607-DI-T, a 2.6 liter four-cylinder direct-injection diesel with a mechanical in-line pump. It takes four. It does not fit the non-turbo V2607-DI, which takes 1J730-53002, or the common-rail V2607-CR.

Is 1J700-53002 the same injector as Bobcat 7020613?

Yes. Bobcat sells this Kubota injector as 7020613. Bobcat used more than one engine in the same loader models, so call 530-668-0818 with the machine serial number and we will check it.

My old injectors are marked 1J700-53000. Can I fit this one?

It is Kubota’s replacement, but not a straight swap. Kubota’s parts list says to order the new holder together with the overflow pipe joint bolt, 1C020-95810, as a set. Send us the engine serial number and we will sort out the bolts with you.

Is it new or remanufactured?

New, genuine Kubota. It is the complete injector, which Kubota calls a nozzle holder assembly, not a nozzle tip alone.
